MVSC-460
Purpose of directional valve : Allow/Shut compressed air to flow into different paths from one or more sources.
Body width: 46 mm,Port size: G1/2, Operating pressure range: 0.2~0.8 MPa, Proof pressure: 1 MPa, Flow: 1633~2722 Nl/min.
| Body width | 46 mm |
|---|---|
| Bore No. | 15A |
| Port size | G1/2 |
| No. of port | 3,5 |
| No. of position | 2,3 |
| Medium | Air |
| Operating pressure range | 0.2~0.8 MPa, 0.3~0.8 MPa (5/3) |
| Proof pressure | 1 MPa |
| Flow | 1633~2722 l/min |
| Effective orifice | 60, 50 mm2(5/2), 30 mm2(5/3) |
| Response time | 50 ms |
| Ambient temperature | －5~＋50℃ (No freezing) |
| Voltage | AC110V, 220V (50/60)Hz, DC24V |
| Power consumption | AC=4.8/4.4VA, 6/4.9VA, DC=2W |
| Available voltage range | ±10% |
| Insulation class | F class |
| Weight | 325g, 455g, 339g, 464g, 525g |
