BES M30MI-PSC15B-S04G Cảm biến tiệm cận

Liên hệ

Giao hàng COD toàn quốc

Mô Tả Sản Phẩm

Order code: BES00AF

BES M30MI-PSC15B-S04G

Our standard inductive sensors are ideal for object detection in metal areas. They are short-circuit protected and operate without contact, making them wear-free and very resistant to dirt and contamination. The sensors are available in configurations from 3 mm Ø to 80 × 80 mm square dimensions.
The rugged and reliable inductive Global Sensors provide especially economical solutions. We can also delivery the broad range of these over 500 preferred types worldwide in the shortest possible time.

Key features

DimensionØ 30 x 65 mm
StyleM30x1.5
Installationfor flush mounting
Range15 mm
Switching outputPNP normally open (NO)
Switching frequency100 Hz
Housing materialBrass
Surface protectionNickel-free coated
Material sensing surfacePA 12
ConnectionConnector, M12x1-Male, 4-pin
Operating voltage Ub10…30 VDC
Ambient temperature-25…70 °C
IP ratingIP67
Approval/ConformityCE, cULus, EAC, WEEE
