Van điện từ MVSC-260 Mindman

MVSC-260 Series

Purpose of directional valve : Allow/Shut compressed air to flow into different paths from one or more sources.

Design change : Coil color (black→gray)

Body width: 26 mm, Port size: Rc1/4, Operating pressure range: 0.2~0.8 MPa,Proof pressure: 1 MPa, Flow:  871, 980 l/min.

Body width	26 mm
Bore No.	8A
Port size	Rc1/4
No. of port	5
No. of position	2,3
Medium	Air
Operating pressure range	0.2~0.8 MPa, 0.3~0.8 MPa (5/3)
Proof pressure	1 MPa
Flow	980 Nl/min, 871 Nl/min (5/3)
Effective orifice	18 mm2, 16 mm2 (5/3)
Response time	40 ms
Ambient temperature	－5~＋50℃ (No freezing)
Voltage	AC110V, 220V (50/60)Hz, DC24V
Power consumption	AC=4.8/4.4VA, 6/4.9VA, DC=2W
Available voltage range	±10%
Insulation class	F class
Weight	203g, 322g, 327g
