MACP300L

Longer case for adapting high efficient auto drain valve. Components : MAFR300L, MAL300L, Port size: 1/4, 3/8, Operating pressure range : 0.05~1 MPa, Proof pressure : 1.5 MPa.

Purpose of Air units (Air preparation):

Filter: To eliminate particle, condensation and impurities in the compressed air.

Regulator: Reduce the mainline compressed air to safe and usable pressures and maintain constant operating pressure.
Lubricator: Injects lubricant into an air line to provide lubrication to the internal working parts of pneumatic tools or components.

Components	MAFR300L, MAL300L
Bore No.	8A,10A
Port size	1/4, 3/8
Medium	Air
Operating pressure range (※)	0.05~1 MPa
Proof pressure	1.5 MPa
Regulated pressure range	0.05~0.85 MPa
Ambient temperature	－5~＋60℃ (No freezing)
Filter element	Standard:5μm Option:40μm
Lubricating oil capacity	65c.c
Min. flow for oil drip	50 l/min,60 l/min
Recommended lubricating oil	Turbine oil ISO-VG32
Attachment	Pressure gauge (PG-40), T-type bracket
Weight	739 g
Remark	1.Standard unit contains semi-auto-drain function when operating pressure below 0.05 MPa. 2.Choose auto-drain FMRF300,the pressure range is 0.15~1 MPa.
